Leoch DJM1290H
Leoch DJM1290H
Specification
Number of elements in the block
6
Rated voltage
12 B
Nominal capacity (С10)
90 Ah at 10-час discharge to U 1.80 W/El at 25 ˚С
Weight
27.1 kg ± 3%
Internal resistance
5.5 mOhm
Short circuit current
2070 А
Operating temperature range
-40 °C ~ 60 °C (Оптимальная рабочая темп.: 25 °C)
Charge voltage
Буферный режим –2.25-2.30 W/El, Temperature coefficient –3 мW/El/˚С., Cyclic mode –2.35-2.40 W/El, Temperature coefficient –5 мW/El/˚С.
Maximum charge current
0.3 С
Self-discharge
≤3% в month at 25 ˚С. Могут храниться to 6 months at 25 ˚С, after which a charge is required. Higher temperatures reduce shelf life.
dimensions
Length: 306 ± 2 мм, Width: 168 ± 2 мм, height (макс.): 214 ± 2 мм
Housing material
ABS (acrylic butadiene styrene)
Output type
Под внутренний болт М8 (torque 11.0-14.7 Нм)
Life time
12 years in buffer mode или более 260 cycles заряда-разряда в циклическом режиме at 100% discharge
Технология
AGM
*The battery must be charged before use. At higher ambient temperatures, storage time is reduced
*The content may be changed for improvement without prior notice, it is not a public offer.
*The appearance of the product may differ from that shown on the website.
Dimensions
Length
306
Width
168
Height
208
Height (full)
214
Direct current discharge: А (25°С)
| Uk. / Tdischarge | 10 min | 15 min | 20 min | 30 min | 45 min | 1 h | 2 h | 3 h | 4 h | 5 h | 6 h | 8 h | 10 h | 20 h |
| 1.85 V/Эл | 134.5 | 116.6 | 91.7 | 82.0 | 60.0 | 50.8 | 30.9 | 22.7 | 17.8 | 15.5 | 13.6 | 10.5 | 8.68 | 4.61 |
| 1.80 V/Эл | 152.6 | 132.1 | 103.7 | 89.3 | 63.5 | 52.6 | 32.0 | 24.6 | 19.0 | 16.3 | 14.6 | 11.0 | 9.00 | 4.77 |
| 1.75 V/Эл | 165.5 | 143.0 | 111.9 | 91.1 | 65.8 | 55.2 | 33.6 | 25.1 | 19.4 | 16.5 | 14.8 | 11.1 | 9.18 | 4.82 |
| 1.70 V/Эл | 176.5 | 151.9 | 118.7 | 92.9 | 67.1 | 56.3 | 34.3 | 25.6 | 19.7 | 16.8 | 14.8 | 11.2 | 9.27 | 4.87 |
| 1.67 V/Эл | 182.1 | 156.3 | 121.9 | 94.3 | 68.1 | 57.1 | 34.8 | 25.8 | 20.0 | 17.2 | 14.9 | 11.4 | 9.39 | 4.93 |
| 1.60 V/Эл | 188.3 | 161.2 | 125.0 | 95.6 | 69.1 | 58.0 | 35.3 | 26.1 | 20.2 | 17.4 | 15.0 | 11.6 | 9.50 | 4.99 |
Constant power discharge: W/El (25°С)
| Uk. / Tdischarge | 10 min | 15 min | 20 min | 30 min | 45 min | 1 h | 2 h | 3 h | 4 h | 5 h | 6 h | 8 h | 10 h | 20 h |
| 1.85 V/Эл | 253.0 | 220.8 | 174.4 | 156.7 | 115.3 | 98.2 | 60.2 | 44.4 | 34.9 | 30.4 | 26.9 | 20.8 | 17.3 | 9.17 |
| 1.80 V/Эл | 283.0 | 246.9 | 195.1 | 169.2 | 121.3 | 101.2 | 61.9 | 47.9 | 37.2 | 31.9 | 28.8 | 21.8 | 18.1 | 9.49 |
| 1.75 V/Эл | 302.0 | 263.6 | 208.2 | 171.4 | 125.0 | 105.7 | 64.8 | 48.7 | 37.7 | 32.3 | 28.9 | 21.9 | 18.2 | 9.57 |
| 1.70 V/Эл | 317.5 | 277.1 | 218.9 | 173.3 | 126.6 | 107.2 | 65.9 | 49.5 | 38.2 | 32.8 | 29.0 | 22.2 | 18.4 | 9.66 |
| 1.67 V/Эл | 322.7 | 281.6 | 222.5 | 174.5 | 127.7 | 108.2 | 66.6 | 49.7 | 38.7 | 33.3 | 29.1 | 22.4 | 18.6 | 9.77 |
| 1.60 V/Эл | 327.2 | 285.5 | 225.6 | 175.3 | 128.4 | 109.0 | 67.1 | 49.9 | 39.0 | 33.7 | 29.2 | 22.7 | 18.8 | 9.87 |
