WBR GPL12200

Specification

Number of elements in the block
6
Rated voltage
12 V
Nominal capacity (при 25 °C)
20 Ah at 20-hour discharge to Uкон. 10.5 V (1.75 V/эл.)
Weight
5.95 kg ± 3%
Maximum discharge current (5 sec)
300 A
Short circuit current
1000 A (согласно IEC 60896-21-22)
Internal resistance
10 mOhm
Operating temperature range
Discharge: from -40 °C to +60 °C, Charge: from -20 °C to +60 °C, Storage: from -40 °C to +60 °C
Rated operating temperature
25 °C
Charge voltage
13.5 - 13.8 V at 25 °C (темп. комп. -3 мВ/˚С/Эл.)
Maximum charge current
6.0 A
Charge voltage in cyclic mode
14.4 - 15.0 V at 25 °C (темп. комп. -5 мВ/˚С/Эл.)
Shelf life
to 6 months at 25 °C, without recharge*
Terminals/ Момент затяжки соединения
for bolt с гайкой М5 / 4-6 Нм
Housing material
Shockproof ABS (acrylic butadiene styrene)

*The battery must be charged before use. At higher ambient temperatures, storage time is reduced

Dimensions

Length
181
Width
76
Height
167
Height (full)
167

Direct current discharge: А (25°С)

Uk/Tdischarge2 min4 min5 min6 min8 min10 min15 min20 min30 min45 min1 h1.5 h2 h3 h4 h5 h8 h10 h20 h
1.85 V11278.573.467.961.551.240.032.522.716.511.69.276.164.733.883.302.141.900.952
1.80 V12897.281.475.965.755.041.634.023.917.412.210.16.564.903.973.372.231.960.984
1.75 V13510488.583.269.557.243.034.924.318.112.710.86.905.004.043.422.302.001.01
1.70 V14210993.285.071.258.843.735.224.518.613.111.17.165.084.093.462.322.021.03
1.67 V14811396.586.572.460.044.535.524.718.813.511.37.435.114.123.482.332.031.04
1.65 V15411699.087.573.361.245.135.824.919.213.711.57.565.174.153.502.342.041.05
1.60 V15911810188.273.962.245.536.025.119.513.911.67.705.214.173.512.352.051.05

Constant power discharge: W/El (25°С)

Uk/Tdischarge2 min4 min5 min6 min8 min10 min15 min20 min30 min45 min1 h1.5 h2 h3 h4 h5 h8 h10 h20 h
1.85 V19916214814411593.465.260.839.534.922.718.512.29.537.636.654.593.551.92
1.80 V22818016115112310172.264.243.235.823.819.312.79.887.936.884.753.721.98
1.75 V25019116915612710878.466.946.236.624.619.813.010.18.127.004.833.802.02
1.70 V25919817516113111079.267.347.037.125.420.113.510.38.227.104.883.822.06
1.67 V26720017816513411280.067.747.637.626.220.313.610.48.327.134.913.842.09
1.65 V27120218116813611480.668.148.237.926.620.513.710.58.407.164.933.862.12
1.60 V27420418417013811681.068.548.638.226.820.613.810.68.467.184.953.882.15
